Kirisun-Portable Walkie Talkie Radio Comunicador, Professional 2 Way Radio, PT5200, 16CH, 4-10km, 5W

T5200 General

Frequency Range

136~174MHz, 400~470MHz
470-512MHz, 500~528MHz

Channel Capacity

16

Channel Spacing

12.5KHz/20KHz/25KHz

Operating Temperature

-30℃~ +60℃

Operating Voltage

7.5V DC ±20%

Battery

 1200mAh Li-poly(Standard)

Frequency Stability

±2.5 ppm

Dimension(with battery and antenna)

57mm×102mm×30mm

Weight(with battery and antenna)

235g

Transmitter

RF Power Output

4W/2W/0.5W(UHF)

5W/2W/0.5W(VHF)

Frequency Modulation

16KφF3E/11KφF3E

Antenna Impedance

50Ω

Modulation Limiting

±2.5KHz @12.5KHz, ±4KHz @ 20KHz, ±5KHz @ 25KHz

Radiated Spurious Emission

-36dBm < 1GHz
-30dBm > 1GHz

FM Noise

40dB @ 20/25KHz
35dB @ 12.5KHz

Modulation Distortion

< 3%

Receiver

Reference Sensitivity

0.28μV @12.5KHz
0.25μV @ 20/25KHz typical

Adjacent channel Selectivity

60dB @ 12.5KHz
70dB @ 20/25KHz

Intermodulation

65 dB

Spurious Response Rejection

70 dB

Rated Audio Output

0.5W

S/N

40/35

Rated Audio Distortion

≤3%
