- Output Power(w):Â 3w-5w
- Battery Capacity(mAh):Â 1500
- Waterproof / Water-Resistant:Â IP66
- Storage Channel:Â 48
- Frequency Range:Â UHF VHF
- Model Number:Â BD610
- Walkie Talkie Type:Â Portable
- Is_Display:Â No
- Maximum Range:Â 5km-10km
- Brand Name:Â Hytera
- Origin:Â Mainland China
Specification
|
General
|
|||
|
Frequency Range
|
146-174MHz/400-470MHz
|
||
|
Channel Capacity
|
48
|
||
|
Operated Voltage
|
3.7V
|
||
|
Battery Capacity
|
1500mAh Li-ion
|
||
|
Battery Life(5-5-90 duty cycle)
|
About 10-24hours
|
||
|
Frequency Stability
|
±2.5ppm
|
||
|
Operated Temperature
|
-25℃~+55℃
|
||
|
Antenna Impedance
|
50 Ω
|
||
|
Dimensions
|
108×54.5x28mm
|
||
|
Transmitter
|
|||
|
RF Power Output
|
≤3.5W
|
||
|
Modulation
|
F3E
|
||
|
Spurious Emission
|
65dB
|
||
|
FM Noise
|
45dB(W)/42dB (N)
|
||
|
Audio Distortion
|
≤5%
|
||
|
Transmitting Current
|
1.2A
|
||
|
Receiver
|
|||
|
Sensitivity(12dB SINAD)
|
≥0.2μv
|
||
|
Inter-modulation
|
≥65dB
|
||
|
Adjacent Channel Selectivity
|
≥60dB
|
||
|
Spurious Response
|
≥60dB
|
||
|
FM Noise
|
45dB(W)/42dB(N)
|
||
|
Audio Distortion
|
≤5%
|
||
