Hytera-BD610 BD615 Talkie-Walkie, Numérique Wireless, High Power, Remote, Portatif Station, Outdoor Site
$235.00
Output Power(w): 3w-5w
Battery Capacity(mAh): 1500
Waterproof / Water-Resistant: IP66
Storage Channel: 48
Frequency Range: UHF VHF
…
Description
- Puissance de sortie (W) :3w-5w
- Capacité de la batterie (mAh) :1500
- Étanche / Résistant à l’eau :IP66
- Canaux de stockage :48
- Gamme de fréquences :UHF VHF
- Numéro de modèle :BD610
- Type de talkie-walkie :Portable
- Avec écran :No
- Portée maximale :5km-10km
- Marque :Hytera
- Origine :Mainland China
Specification
General | |||
Frequency Range | 146-174MHz/400-470MHz | ||
Channel Capacity | 48 | ||
Operated Voltage | 3.7V | ||
Battery Capacity | 1500mAh Li-ion | ||
Battery Life(5-5-90 duty cycle) | About 10-24hours | ||
Frequency Stability | ±2.5ppm | ||
Operated Temperature | -25℃~+55℃ | ||
Antenna Impedance | 50 Ω | ||
Dimensions | 108×54.5x28mm | ||
Transmitter | |||
RF Power Output | ≤3.5W | ||
Modulation | F3E | ||
Spurious Emission | 65dB | ||
FM Noise | 45dB(W)/42dB (N) | ||
Audio Distortion | ≤5% | ||
Transmitting Current | 1.2A | ||
Receiver | |||
Sensitivity(12dB SINAD) | ≥0.2μv | ||
Inter-modulation | ≥65dB | ||
Adjacent Channel Selectivity | ≥60dB | ||
Spurious Response | ≥60dB | ||
FM Noise | 45dB(W)/42dB(N) | ||
Audio Distortion | ≤5% | ||
Informations complémentaires
| Technology |
|---|
| IP Rating |
| Power |
| Frequency Band |
Specifications
Detailed specifications available upon request. Contact our sales team for full technical documentation.
Downloads
Contact us for product datasheets, firmware updates, and programming software.
